Orbbec Gemini 2L Stereo Vision Camera with Active IR Technology
The Orbbec Gemini 2L employs advanced active stereo infrared technology featuring a 100mm stereo baseline configuration. This cutting-edge 3D camera incorporates Orbbec's newest proprietary ASIC processor to deliver exceptional depth computation performance. The system achieves an impressive diagonal depth Field of View (FoV) reaching 101° while providing streamlined USB 3.0 connectivity through a unified cable solution for power delivery and data transmission.
This sophisticated camera integrates a proximity detection system for precise close-range single-point measurements, ensuring complete depth coverage throughout the 0-10m operational spectrum without measurement gaps. An integrated IMU sensor provides motion detection and positional tracking capabilities. The Gemini 2L offers simple installation and configuration through the comprehensive Orbbec SDK, ensuring consistent data capture across diverse lighting environments, from zero-light scenarios to semi-outdoor conditions.
Core Capabilities
Extensive Scene Analysis and Detection Range
Precision Distance Analysis
Uninterrupted Depth Data Collection
Advanced Multi-Device Coordination
Superior Performance in Motion-Rich Environments
Application-Optimized Operating Modes
Gemini 2L Specifications
Camera Specifications
| Parameter | Specification |
|---|---|
| Depth Technology | Active Stereo IR |
| Wavelength | 850nm |
| Depth Range | 0.2 - 10m |
| Depth Resolution/FPS | Up to 1280X800@30fps |
| Depth FOV | H91° V66° |
| RGB Resolution/FPS | Up to 1280X800@30fps |
| RGB FOV | H94° V68° |
| Processing | Orbbec ASIC |
| IMU | Supported |
*Precision: ≤ 2% @ 4m
Physical Parameters
| Parameter | Specification |
|---|---|
| Data Connection | USB 3.0 & USB 2.0 |
| Power Input | DC 5V ± 2.0A |
| Trigger | Supported |
| Power Consumption | Typical average < 3.0W/Max peak value < 10.0W |
| Operating Environment | 0℃ - 40℃, 8%RH - 90%RH (non - condensing), Indoor/Semi - Outdoor |
| SDK Support | Orbbec SDK |
| Data Output | Point Cloud, Depth Map, IR & RGB |
| Dimensions (WHD) | 124mm x 29mm x 26 mm ± 0.5mm |
| Weight | 152g ± 2g |
| Installation | 1 x 1/4 - 20 UNC thread mounting point 2 x M3 thread mounting points |
Use Cases
