Seeed Studio MQ7813T120 PoE Module Kit for reTerminal DM & R1000
The MQ7813 series of PoE modules is designed to be a reliable and efficient power source ๐ for small-power applications such as IP cameras ๐ท, IP phones ๐, industrial sensors โ๏ธ, and gatekeepers. It extracts power from a conventional twisted pair Category 5 Ethernet cable ๐ and conforms to the IEEE 802.3af Power-over-Ethernet (PoE) standard.
๐ง Features
- ๐ Wide operating voltage range: 40V to 57V, providing flexibility for various applications.
- ๐ Dual output current options: 5V at 2A and 12V at 1.1A, suitable for different device requirements.
- ๐ Low output voltage ripple: Only 70mVpp (5V at 2A), ensuring stable and reliable output.
- โก High efficiency: 86% efficiency at 48V input and 12V/1.1A load, reducing energy waste.
- ๐ก๏ธ High reliability: 500k hour MTBF, overcurrent/short circuit protection, UL/IEC/EN60950 compliant, ROHS option available.
๐ Description
The MQ7813 series enhances PoE power delivery by providing up to 13W output through its signature and control circuit, ensuring compatibility with Class 0โ3 equipment. The built-in high-efficiency DC/DC converter operates across a wide input voltage range and delivers low ripple, low-noise regulated output.
With dual output options (5V/2A, 12V/1.1A), the MQ7813 is ideal for powering diverse devices. Its low ripple (70mVpp) guarantees stable voltage, while 86% efficiency ensures effective energy conversion. Designed for long-term reliability, it features 500k hour MTBF, overload and short-circuit protection, and compliance with UL/IEC/EN60950 and ROHS.
๐ก Application
- ๐ท IP Camera
- ๐ IP Phone
- ๐ถ Wireless Access Point
- ๐ฅ Video Supervisory
๐ Specification
๐ฅ๏ธ Hardware Overview
๐ฆ Part List
- 1 ร MQ7813T120 PoE Module Kit for reTerminal DM
๐ Certification
- HS CODE: 8517180050
- US HS CODE: 8517180050
- EU HS CODE: 8543709099
- UPC: โ
- ๐ Country of Origin (COO): China
