Waveshare ESP32-S3 With 3.49inch IPS Capacitive Touch Display 172 × 640
🚀 ESP32-S3 3.49-inch Touch LCD Development Board
The ESP32-S3 3.49-inch Touch LCD Development Board is a high-performance, highly integrated solution featuring a 3.49-inch IPS capacitive touch display. It includes QSPI display connectivity, audio input/output capabilities, and supports AI interaction and offline voice control.
🔋 Version Options
This development board is available in several configurations to suit your project needs:
ESP32-S3-Touch-LCD-3.49B-EN Case B version, without battery
💻 LCD Parameters
| Display Panel | LCD | Display Size | 3.49 inch |
|---|---|---|---|
| Resolution | 172 × 640 | Display Colors | 16.7M |
| Brightness | 350 cd/m² | Contrast Ratio | 1200:1 |
| Display Interface | QSPI | Driver IC | AXS15231B |
| Touch Interface | I2C | Touch Type | Capacitive touch |
🛠️ Key Features
The ESP32-S3-Touch-LCD-3.49 is a high-performance microcontroller development board designed by Waveshare.
-
ESP32-S3R8 Xtensa 32-bit LX7 dual-core processor, up to 240MHz
-
Wi-Fi 2.4GHz (802.11 b/g/n) and Bluetooth 5 (LE)
-
512KB SRAM + 384KB ROM, onboard 8MB PSRAM + external 16MB Flash
-
3.49-inch IPS capacitive touch display, 172×640 resolution, 16.7M colors
-
Dual microphone array with noise reduction + echo cancellation
-
AXS15231B LCD & touch controller (QSPI + I2C)
-
QMI8658 6-axis IMU (accelerometer + gyroscope)
-
PCF85063 RTC chip
-
Programmable PWR + BOOT buttons
-
Battery support: 3.7V MX1.25 Lithium or 18650 holder
-
TF card slot for storage & media playback
-
22PIN expansion pads for external modules
🎵 Onboard Audio Codec
Supports high-quality audio processing, providing clear and high-fidelity input/output.
🤖 Supports AI Speech Interaction
Allows access to online large model platforms (DeepSeek, Doubao, etc.), expanding AI-powered applications.
🌈 IPS Display Panel
Excellent display performance with 16.7M colors and wide viewing angle.
👆 Capacitive Touch
Ideal for smart device development, enabling intuitive human-machine interaction.
🧰 Two Case Options
Choose between Case A and Case B to suit your needs. (Refer to package content for detailed part list.)
💻 Development Support
Compatible with ESP-IDF and Arduino IDE, with rich SDK resources.
🌐 Wi-Fi and BLE 5 Support
-
Wi-Fi 2.4GHz with 40MHz bandwidth
-
Bluetooth 5 LE + Mesh for robust connectivity
📋 What's On Board
-
ESP32-S3R8
Wi-Fi and Bluetooth SoC, up to 240MHz operating frequency, with onboard 8MB PSRAM -
Onboard antenna
supports 2.4GHz Wi-Fi (802.11 b/g/n) and Bluetooth 5 (LE) -
TCA9554PWR
8-bit I2C GPIO expansion chip -
W25Q128JVSI
16MB Flash memory -
ES8311 DAC audio encoding chip
high-performance, low-power audio DAC -
ES7210 ADC audio decoding chip
high-performance, low-power audio ADC, supports multiple microphone inputs -
QMI8658
3-axis gyroscope and 3-axis accelerometer, suitable for applications such as attitude sensing and motion recognition -
Dual microphone array design
dual-digital microphone, supports more advanced voice interaction functions
-
TF card slot
supports FAT32-formatted TF card for data expansion -
RESET button (back side)
press the BOOT, then click the RESET button to enter download mode -
PWR power button (back side)
Enables power control via software configuration when using Lithium battery for power supply -
BOOT button (back side)
press the BOOT, then click the RESET button to enter download mode -
MX1.25 2PIN speaker header (back side)
audio signal output, for connecting external speaker -
IPEX1 connector
for connecting external antenna, enabled via resoldering an onboard resistor -
22PIN 2.54mm pitch through-hole pads
for connecting external modules and enabling functional expansion -
Type-C port
for program burning and log printing -
PCF85063
RTC clock chip, supports time retention
📐 Outline Dimensions
ESP32-S3-Touch-LCD-3.49
ESP32-S3-Touch-LCD-3.49B
