M5Stack NanoC6 Dev Kit
The M5NanoC6 is a compact, low-power IoT development board that belongs to the M5Stack development kit series. Powered by the ESP32-C6FH4 MCU, it supports advanced Wi-Fi 6 (2.4GHz 802.11ax), Zigbee, Thread, and Matter wireless protocols. The board includes a built-in infrared LED for controlling IoT devices remotely and features an RGB indicator for visual feedback. Its ceramic antenna ensures a reliable wireless connection, while the Grove port allows easy integration with other devices in the M5Stack ecosystem.
Key Features of M5NanoC6
-
Support for Wi-Fi 6, Zigbee, Thread, and Matter
The M5NanoC6 is equipped with 2.4GHz Wi-Fi 6 (802.11ax) and backward compatibility with 802.11b/g/n. It also incorporates Zigbee, Thread, and Matter protocols, providing extensive connectivity options for smart home and IoT applications. -
Infrared LED & RGB Indicator
The infrared LED allows for remote operation of household appliances, while the programmable RGB indicator enhances interactivity through visual effects in your projects. -
Grove Expansion Interface & M5Stack Ecosystem
The Grove port accommodates UART, I2C, and additional communication protocols, enabling developers to connect effortlessly with M5Stack ecosystem devices to broaden hardware functionalities. -
Reliable Connectivity with Ceramic Antenna
The integrated ceramic antenna delivers a stable wireless connection, ensuring optimal signal performance for IoT applications. -
Compact and Low-Power Design
Thanks to its small size and energy-efficient operation, the M5NanoC6 is perfect for battery-powered projects, supporting efficient operations in smart home automation, industrial control, health monitoring, and other IoT solutions.
How to Enter Download Mode for Firmware Burning
- Press and hold the GPIO9 button.
- Connect the data cable to activate download mode.
With features like Wi-Fi 6, Zigbee, Thread, and Matter support, infrared functionality, Grove expansion, and a compact low-power design, the M5NanoC6 is an ideal IoT development board suitable for smart home, industrial automation, and health monitoring applications.
Arduino IDE
Includes
- 1x M5NanoC6
Applications
- Intelligent housing systems
- Industrial control systems
- Environmental monitoring systems
- Agricultural IoT systems
- Medical applications
- Consumer electronics
- Service robots
Specification
| Resources | Parameters |
|---|---|
| SoC | ESP32-C6FH4 @ RISC-V 160MHz, 4M Flash, Wi-Fi 6, Zigbee 3.0, Thread 1.3, Matter, CDC |
| WIFI protocol | 2.4GHz Wi-Fi 6 (802.11ax), backward compatible with 802.11b/g/n |
| RGB | WS2812 |
| IR remote control parameters | Infrared emission distances: < 0° - 632CM; < 45° - 83CM; < 90° - 29CM |
| Grove outputs maximum current | DC 5V @ 600mA (output capacity depends on USB power supply) |
| Standby current (Deep Sleep Mode) | Type-C power supply DC 5V @ 125.5uA; Grove power supply DC 5V @ 50uA |
| Standby current (ULP Mode) | Type-C power supply DC 5V @ 252uA; Grove power supply DC 5V @ 201.5uA |
| Operating current | In WIFI mode: DC 5V @ 106.2mA |
| WI-FI stretch test (antenna backup, back alignment test) | 54.9m |
| Operating temperature | 0-40°C |
| Product Size | 23.5 * 12 * 9.5mm |
| Package Size | 110 * 81 * 11mm |
| Product Weight | 2.5g |
| Package Weight | 11.2g |
